Molex Cable: What you will needįollowing is the list of components that you will require for the process. Here is the complete guide on installing and removing Molex connectors from a system. That is why you can find Molex connectors on every other device. Molex installation is not complicated if you have the right components and skills on hand.
2 pin molex connector how to#
How to Install and Remove Molex Connectors?
Additionally, it is not only Molex and AMP that make compatible connectors there are other manufacturers. The devices include the motherboard, fans, floppy disc drive, CD/DVD drive, video card, and the older complex drive models. Not only Desktop, but you can also use the Molex connectors to supply power to various devices. Several different connection types are now standard for connecting electricity to desktop computers due to the Molex design’s simplicity, dependability, versatility, and low cost. Molex Cable: What is the use of Molex Connector in Desktop PC? Also, it is recommended for applications where you want to fit the wires into the plug properly. Moreover, it is possible to quickly prototype connectivity applications if you have the resources and prolonged power solutions in virtually any industry and sector because of this versatility.Ĭaption: A 4-pin Molex connector Molex Two Pin ConnectorĪnother widespread Molex connector is the two-position pin and socket connector design.
2 pin molex connector series#
Its 2×2 receptacle matrix has a tiny footprint, so it is an excellent choice for the primary power source on a small printed circuit board (PCB). Thus, it is necessary to use crimp pins to connect your wires to this four-pin Molex receptacle, a 5557 series four-pin plug connector of similar capacity, as the mating connector for this Molex receptacle. In particular, the right angle wire-to-board 5569 series connector, which can accommodate 16 AWG wires with a 4.20mm pitch and deliver 13A of power, is one of the most widely used Molex connectors today. It is suitable for a wide range of power and IO connector applications. Since it can take many forms according to the industry, the Four-Pin version is the most popular Molex connector configuration. Still, let’s see what popular connectors are available across the market. Thus, when it comes to choosing the suitable Molex connector to link hardware 1 to hardware 2, it is often not that simple. You will need the one that suits you best from multiple types of connectors.
Therefore, you can often use connectors for power since the pins have a wide contact surface and fit firmly.Ĭaption: Molex connector in automotive parts Common types of Molex Connectors Here, the 1.57 mm pin can handle up to 5A, while the 2.36 mm pin can handle 8.5A. Also, in a single housing, you may place pins and sockets in any configuration. Such connectors usually have two to twenty-four contacts and are polarised or keyed to assure proper alignment. Moreover, the plugs and sockets are housed in a rectangular matrix inside a nylon shell. Cylindrical spring-metal pins slide into cylindrical spring-metal sockets in this kind of connection. In addition, the term “Molex connector” refers to a two-piece pin and socket interconnection. The most common example is the 4-pin connector used for personal computer power, especially pre-SATA disk drives. Typically, we refer to cables with Molex connectors as Molex cables.
